Dart3D Target Mounts - Autodarts Setup Guide

Thank you for purchasing your Autodarts Mounts from my store—I really appreciate it!

This guide relates to Dart3D Target Mounts

I hope you’re happy with your camera mounts. If you have any questions or issues, please get in touch and I’ll do my best to help. My aim is to get you up and running with Autodarts as smoothly as possible.

We also sell on eBay as Hippo3dPrints.

A few important notes:

  • All of the screws you need are included.
  • These mounts are designed for OV9732 cameras.
  • (If you purchased without cameras) When your cameras arrive, you may need to break off the outer edge of the board for them to fit—this is standard practice for these models. Let me know if you need more help with this.
  • The mounts clip onto the Target Corona Vision and should be placed at the optimal positions (see below).
  • Please do not use any powertools or drills with 3d prints, and do not place in direct sunlight or use in conditions over 50°c.
  • You can also find many helpful people in the Autodarts Discord.

Camera set up

If you bought mounts with cameras, skip to the Installation step

If your cameras have arrived with an outer border like below, you will need to remove them in order for them to fit in the mount

ov9732 cameras for Autodarts

I usually remove them by clipping the corners with wire cutters and then gently pulling at the border with up and down motions:


Once the cameras are the right size, they can be screwed into the mount, using 2 screws.

Pass the cable through the bottom of the mount, clip first (not the usb end). Once fed through, you can connect the clip to the camera.

The cable port should be at the top of the mount:


Installation

Once the cameras have been installed the mounts can be connected to the light ring. Place them in one of the optimal positions as below:

Autodarts Camera Positioning

The mounts can be clipped on to the ring as shown below. They can be removed by pulling the top clip back until it clicks off:


Plug all three USB cables into USB 2.0 ports on your device and load up the Autodarts software.

You may need to adjust the focus by gently twisting the camera lens whilst viewing the camera through the Autodarts client. Be very careful doing this, as overtightening will destroy the camera.

A great tip for focusing is placing a card or any small piece of paper with text and wedging it between the board and surround opposite the camera position. You can use the text to focus the camera.

Camera Cap and Lens Hood

Your Target Mount should work fine using the normal camera cap, however in some cases lens flare can cause issues with accuracy. This is where light from the light ring causes bright circles, rings, starbursts, or a hazy overall effect in the image, it may appear as a rainbow affect. I have designed a lens hood cap to go with this mount that can be used if this is the case.



Notes that may help:

  • Ensure your Target Corona Light Ring is pushed on properly, this can affect vibration.
  • Tidy away cables behind the board. Make sure there is nothing moving in the view of the cameras, moving cables can trigger takeout mode.
  • Accuracy can be affected by external factors, such as dart colour, dart board, lighting, etc. Robbel has put together a great informative video which may help.
  • Hitting the light ring with a dart or hand will trigger takeout mode with any ring mounted camera - this can not be avoided. If this happens, you will need to click 'calibrate' (the little cross hair button) and/or reset to reset your turn.

If you have any further questions you can contact me via the chat function, by email or by WhatsApp.

If you have any feedback, small or large, good or bad, please let me know via chat, email or Whatsapp. Feel free to come back and submit as much as you like. I really appreciate anything that might help improve this product. And if you like this product, please leave a review (on eBay or this website, or both if you're feeling generous!)

Thank you! See you in a tournament! Jack 🎯
